High-Temperature Vacuum Drying Ovens

Laboteck is a company specializing in vacuum oven manufacturers who used high vacuum ovens technology for laboratories, industrial and research areas, selling products, services, integrated solutions, and providing technical assistance.

Laboteck is a leading provider of high-temperature vacuum ovens for inert atmospheres. The range includes an annealing furnace with high temperatures up to 2800 degrees Celsius (° C) that operates in high vacuum, ultra-high vacuum, and inert atmospheres, nitrogen, hydrogen, and reducing gases.



The Applications Of the Vacuum Oven Are:

  • Welding
  • Diffusion and bonding
  • Extensometry
  • Hot pressing
  • Extinction
  • Fusion
  • Sintering,
  • Crystal growth
  • Degassing
  • Glass processing
  • Heat treatment

These are products developed with the latest technology and according to the main requirements of biochemists, pharmacists, and scientists, such as micropipettes, photometers, laboratory centrifuges, microscopes, analytical scales, semi-analytical, and various other materials to perform experiments, calculations, biological or chemical measurements, and analysis.

The vacuum furnace is generally used for the sterilization, cooking, and drying of non-volatile materials and for heat treatment for mining companies, schools, and medical and scientific researchers. It is particularly useful for the simultaneous drying of small amounts of different polymer types used in trial molding processes. It is also used in areas such as electronics engineering, electrocoating, pharmaceuticals, paint baking, and printing for materials related to preheating or drying.



Function and Feature of Our Vacuum Oven:

  • Timer heating off
  • Alarm feature by heat buzzer
  • Temperature correction
  • Overheat shutdown
  • Adjustment of the heating power percentage
  • Precision temperature control with a resolution of 0…1 ° C
  • Digital direct reading display, easy to operate temperature control
  • Large transparent tempered glass, easy to observe the object
  • Material: Stainless steel
  • Suitable for drying of heat-sensitive samples and experiments under inert gas
  • Control system with programmable PID microprocessor
  • Digital display for temperature and time, easy to use control panel
  • Stainless steel cell which is resistant to contamination, much chemical vapor, and corrosion
  • One-piece silicone seal that can be easily mounted on the body
  • Manometer to observe pressure changes in the cell
  • Two ball valves for vacuum connection and the addition of dry air or inert gas
  • Heat-resistant observation window on the door



Specifications of Our Vacuum Ovens:

  • Silicone pressure seal provides excellent insulation in the box.
  • Glass fiber insulation contributes to effective thermal insulation and energy saving.
  • The heating plate mounted on all four sides of the box ensures temperature uniformity.
  • The temperature sensor ensures stable operation under certain vacuum conditions.



Technical Specification:

Maximum Temperature 200°C
Working Temperature 150 °C
Temperature Fluctuation + / – 1°C
Temperature controller PID Controller or HMI Controller
Sensor type PT100
Doors Solid Door
Heater Kanthal plate & Wire Strip heater
Chamber Design Rectangular or Cylindrical (Round)
Inner chamber SS 304
Exterior Powder-coated galvanized steel/SS 304
Insulation Glass wool
Shelves 1 or 2
Ports Vacuum port, Inert gas port, and Vent port
Safety Device Overpressure limit / Overload breaker / Timer & Alarm, fuse
Vacuum Range 760 mm Hg
Vacuum Control Digital electronic vacuum control through solenoid valves



Optional Accessories

  1. Digital Vacuum Controller
  2. Vacuum Pump
  3. PLC with HMI
  4. Outer SS 304 Construction
  5. Data Logger



Rectangular Vacuum Oven Dimensions

Model Dimensions (W x H x D) Dimensions (W x H x D) Volume
VACUUS 8 8 x 8 x 8 Inch 200 x 200 x 200 mm 8 Liters
VACUUS 28 12 x 12 x 12 Inch 300 x 300 x 300 mm 28 Liters
VACUUS 45 14 x 14 x 14 Inch 355 x 355 x 355 mm 45 Liters
VACUUS 95 18 x 18 x 18 Inch 455 x 455 x 455 mm 95 Liters
VACUUS 127 18 x 18 x 24 Inch 455 x 455 x 609 mm 127 Liters
VACUUS 226 24 x 24 x 24 Inch 609 x 609 x 609 mm 226 Liters



Our company provides a wide range of vacuum ovens to meet numerous needs that can complement each other in integrated solutions. We have accumulated rich experience and valuable technical support in the production of Vacuum ovens. Whenever and wherever, we never give up our goal, which is to provide high quality, competitive prices,s and the best service to our customers.

Laboteck came up with the purpose of providing excellent vacuum oven products, services, and after-sales to its customers. To this end, it represents the best international brands in their respective areas and has a professional sales and service structure, with trained technicians, equipped workshop and spare parts, ensuring quality and agility.

After vacuum oven supplier, in addition to warranty service, we offer preventive maintenance, installation monitoring, and training contracts.

Laboteck guarantees fast and safe delivery of the vacuum oven of your need, if you have any questions, please contact us!
