Microplate readers are the basic tool used in laboratories to detect absorbance, luminescence and fluorescence of molecules. They are widely used in biological sciences. Fully Auto Elisa Microplate Readers are designed for rapid photometric analysis of plates by the ELISA method. The reader can collect measurement results from the entire board in seconds. Such a high measurement speed is ensured by a precise, multi-channel optical system. High accuracy and reliability is ensured by the latest technology.

Fully Auto Microplate readers detect and process biological and chemical data, using mainly absorbance data. They are used in drug discovery, research, bioassay validation and drug manufacturing. The model was designed according to the current technologies, with high quality and reliability, as well as high precision analysis and easy operation. Intuitive software, capable of performing readings, data processing and memorization of analyzes and results.

The Clinical Laboratory Micro Plate Reader has a high resolution, color touch panel and is intended for use in scientific, laboratory and clinical research. It has a small size and solid construction. It is ideal when you need to perform a large number of determinations. The highest quality optics, fast measurement and an excellent incubator are the hallmarks of Laboteck Microplate Reader. These and many other features make it possible to use them for a wide spectrum of applications ranging from ELISA to kinetic studies of cell growth.

Laboteck Microplate Reader/Elisa Microplate Analyser products are the best instruments designed for highly sensitive analyzes, which at the same time require fast and efficient work. Laboteck Microplate Readers have completely new, unique solutions that increase their speed and sensitivity. The Laboteck series readers are the perfect choice for all science laboratories and pharmacological applications. Laboteck ensures the speed, sensitivity and flexibility of conducted research. The use of the latest technologies has ensured that the reader has been designed for the most advanced scientific and clinical laboratory experiments and pharmacological analyzes.

LABOTECK MICROPLATE READER FEATURES

  • Reliable, single-channel absorbance reader for microtiter plates. Determinations: to endpoint, kinetic, well scanning
  • It is possible to use plates from 6 to 96 wells
  • Wavelength range: 340-750 nm, 400-750 nm, 380-900 nm; 340-900 nm
  • Filter wheel: 5-position – up to max. 5 different filters
  • Dynamic range: 0 to 4.0 OD, resolution 0.0001 OD
  • Easy to use Gen5 software for fast data collection and processing as well as exporting and printing results.
  • Typical applications: ELISA
  • Easy-to-use: quickly collecting, exporting and printing data.

The ELISA Microplate analysis device from Laboteck is an easy-to-use micro plate reader. It has a compact structure and is lightweight. It has been designed to measure and interpret enzyme immunoassay results, both monochrome and bichromatic. The ELISA micro plate reader works with flat and convex bottom plates. The tray holding the plate is connected to a special mechanism that smoothly moves it and sets it exactly according to the optimal measurement path. Measurements are made in a continuous mode. The average value of the readings is calculated and presented according to the selected options. The Laboteck reader offers the ability to perform analysis based on absorbance, fluorescence and luminescence.

WHY CHOOSE LABOTECK?

The Laboteck Elisa Microplate Reader Analyser offers proven performance for many applications, from endpoint tests to fast kinetics. The Laboteck Elisa Micro Plate Reader is widely recognized for offering temperature control that optimizes conditions for even the most temperature sensitive tests. Its high quality optical design guarantees excellent precision, accuracy and linearity with easy data capture and powerful analysis. Laboteck is a leading firm and distributor of products and equipment for laboratories, education and industries in general. We have a technical and scientific team to better assist the buyer and user, providing security and agility in the budgeting and purchasing process.



ModelYATHERM 1000
TypeFully automated ELISA analyzer
Sample racks60 or 80 – 12 mm sample tubes or 40 – 16 mm sample tubes
Dilution rack92 positions
Reagents holdermodular racks to hold calibrators, controls and reagents for 8 methods on line
Liquid reservoirsexternal tanks equipped with level sensors; 2 washing buffer
Microtiter plates2 plates (96 wells) with incubation capability, from room temperature to 45 °C
Dispensing system1 aspirating-dispensing probe with X-Y-Z movement; dilution system with a syringe of 1000 μl, continuous flow washing station
Washing systemtwo 8 nozzle on line manifolds with automatic adaptation for the different micro-plates height
Washing Residual volume< 3μl
Washing inaccuracyCV < 5 % with 300 μl
Readingsystem8 independent photometric channels for mono and bichromatic reading
Optical filters2 filters (450 and 630 nm); 2 more on request (max 4 filters)
Readinginaccuracy± 1% from 0.000 to 1.500 OD ± 2% from 1.500 to 3.000 OD
Dispensationfrom 8 ml to 1000 ml with 1μl resolution; inaccuracy ±1% with 100 μl
SoftwareWindows 98 and XP operating system, to set up the work list, patient reports and results filing; calibration curves storage for each carried-out test
ConnectionLIS interface capability, work list set up from Host computer.
Capability of connecting more instruments to a single PC.
Power Supply200/110 VAC, 50-60 Hz
Dimension620 x 820 x 720
Weight80 Kg
